Ali SLIDE Door
Many design options available.
PAS24 security for domestic and commercial use.
Polyamide thermal break for impressive efficiency.
Personalisation Options
Flyscreen
Concealed Drainage
Balustrade
“Ali SLIDE is a slimline, high-performance range of inline aluminium sliding doors with PAS 24 security. This stylish, mid-range, sliding door has been designed to fit all budgets and is suitable for both domestic and commercial use.”
Technical Details
Performance
Energy
Thermal Insulation - Uw = 1.3 W/m2K (Double Glazed)
Thermal Insulation - Uw = 0.9 W/m2K (Triple Glazed)
Comfort
Air tightness = Class 4 (600Pa)
Water tightness = Class 9A (600Pa)
Wind load resistance = Class C4 (1600Pa)
Safety
Burglar resistance = PAS24 & SBD
Overall Dimensions
Size Limits
Sliding Door
Max door leaf width = 2000mm/2500mm
Max door leaf height = 2616mm
Max outer frame width = Project Specific
Max outer frame height = 2700mm
Max weight per door leaf = 150kg/220kg
Glazing
Dimensions
Thickness = 24mm - 44mm
Glazing method
Dry glazing/Siliconised glazing/Internal glazing/Glazing bead
