ConceptFolding 77
Customizable openings to suit preferences.
Leading industry with unmatched element sizes.
Elevated standards for folding doors of superior quality.
Personalisation Options
Low Threshold
Zero Threshold
Concealed Drainage
“Its slender and user-friendly design makes the SlimLine 38 high-insulation system the perfect fit for any contemporary project. The durable aluminium windows and doors offer unlimited design freedom thanks to their multiple minimalistic variants.”
Technical Details
Performance
Energy
Thermal Insulation - Uw = 1.3 W/m2K
Comfort
Air tightness = Class 4 (600Pa)
Water tightness = Class 9A (600Pa)
Wind load resistance = Class C3 (1200Pa)
Safety
Burglar resistance = PAS24RC2
Overall Dimensions
Max. dimension & weight
Min. height of element = 678mm
Max. height of element = 3130mm
Min. height of vent = 600mm
Max. height of vent = 3000mm
Min. width of vent = 400mm
Max. width of vent = 1200mm
Max. weight of vent = 120kg
Glazing
Dimensions
Rebate height = 25mm
Min. glass thickness of frame = 6mm
Max. glass thickness of frame = 63mm
Min. glass thickness of vent = 6mm
Max. glass thickness of vent = 63mm
Glazing method
Dry glazing/Siliconised glazing/Internal glazing/Glazing bead
