PURe
Life expectancy exceeding 40 years.
Wide design and functionality portfolio.
Generic Green Guide rating of ‘A’ for commercial projects.
Personalisation Options
Flyscreen
Balustrade
Concealed Drainage
“The PURe® window range is a revolutionary new range of aluminium windows which uses an innovative, enhanced thermal barrier manufactured from expanded polyurethane (PUR) allowing ultra-low U-values to be achieved.”
Technical Details
Performance
Energy
Thermal Insulation - Uw = 1.2 W/m2K (Double Glazed)
Thermal Insulation - Uw = 0.75 W/m2K (Triple Glazed)
Comfort
Air tightness = Class 4 (600Pa)
Water tightness = Class 9A (600Pa)
Wind load resistance = Class C# (2400Pa)
Safety
Burglar resistance = PAS24 & SBD
Overall Dimensions
Maximum Dimensions
Casement
Top hung Width x Height = 1500mm x 1500mm
Side hung Width x Height = 1000mm x 1500mm
Tilt & Turn
Width x Height = 1500mm x 2400mm
Overswing
Width x Height = 1500mm x 1738mm
Overswing (489mm - 1588mm) Max Weight = 80kg
Overswing (1589mm - 1738mm) Max Weight = 60kg
Parallel
Width x Height = 1500mm x 2400mm
Glazing
Dimensions
Casement
Radius & Stepped Vent Option = 24mm - 36mm
Outer Frames & Flat-faced Option = 24mm - 44mm
Tilt & Turn
Thickness = 28mm - 50mm (48mm for Radius)
Overswing
Radius Vent = 28mm - 48mm
Flat Faced Vent = 28mm - 57mm
Parallel
Radius Vent = 28mm - 48mm
Flat Faced Vent = 28mm - 57mm
Glazing method
Dry glazing/Siliconised glazing/Internal glazing/Glazing bead
