SD Commercial Door
Utilises low thresholds for ease.
Wide design and functionality portfolio.
PAS24:2016 Compliant.
Personalisation Options
Flyscreen
Balustrade
Concealed Drainage
Anti-Finger Stiles
“The aluminium SD Door is capable of being manufactured in single, double, emergency and panic exit door types. It utilises low thresholds and a variety of options such as radius anti-finger trap stiles.”
Technical Details
Performance
Energy
Thermal Insulation - Uw = Calculated on a Project Specific basis (Double Glazed)
Comfort
Air tightness = Class 4 (600Pa)
Water tightness = Class 9A (600Pa)
Wind load resistance = Class C4 (1600Pa)
Safety
Burglar resistance = PAS24 & SBD
Overall Dimensions
Typical Sizes
Standard Hook Door
Max door leaf width = 1100mm (PAS24)
Max door leaf width = 1150mm (Non-PAS24)
Max door leaf height = 2400mm
Panic Doors
Max door leaf width = 1100mm
Max door leaf height = 2200mm
Glazing
Dimensions
Thickness = 6mm - 24mm
Glazing method
Dry glazing/Siliconised glazing/Internal glazing/Glazing bead
