SF62

Wider 62mm box for structural flexibility.

Ideal for ultra high-rise projects.

Enhanced thermal performance, rigorous safety testing.

Personalisation Options

Inclined

Clip-on Cover Cap

Roof

Concealed Drainage

Solar Shading

“SF62, a versatile curtain wall system with a wider 62mm box, is ideal for high-rise projects, offering flexibility in accommodating structural movement and enhanced thermal performance beyond building regulations. Rigorous testing ensures safety and durability, and it is available through custom extrusion for projects where certain products may not meet glass movement requirements.”

Technical Details

Performance

Energy

Thermal Insulation - Uw = Project Specific (Double Glazed)

Thermal Insulation - Uw = Project Specific (Triple Glazed)

Comfort

Air tightness = Class 4 (600Pa)

Water tightness = Class 9A (600Pa)

Wind load resistance = Class C4 (2400Pa)

Overall Dimensions

Sizes

Transom sizes = 80mm to 250mm (80, 100, 125, 150, 175, 200, 225, 250)

Mullion sizes = 72mm to 242mm (72, 92, 117, 142, 167, 192, 217, 242).

Glazing

Dimensions

Thickness = 12mm - 52mm

Glazing method

Dry glazing/External glazing/Pressure plate glazing/Structural Glued Glazing/Structural clamped glazing
