M70 Casement
Multi-chambered, reinforced with steel and aluminum.
Available in various sash sizes, colors, and woodgrain options.
M70 VEKA offers high-performance solutions for diverse applications.
Personalisation Options
Flyscreen
Balustrade
“The M70 VEKA Casement Window sits within an integrated multi-chambered system with sections of reinforced steel and aluminium. Stylish as well as functional; the M70 VEKA casement window is available in a range of sash sizes (top hung, side hung, and fixed light) as well as a large assortment of colours and woodgrain options from our Variations range.”
Technical Details
Performance
Energy
Thermal Insulation - Uw = 1.20 W/m2K (Double Glazed)
Thermal Insulation - Uw = 0.86 W/m2K (Triple Glazed)
Comfort
Air tightness = Class 4 (600Pa)
Water tightness = Class 9A (600Pa)
Wind load resistance = Class C4 (1600Pa)
Safety
Burglar resistance = PAS24
Overall Dimensions
Max. dimension
Maximum sash sizes = Top hung: 1400mm x 1400mm
Maximum sash sizes = Side hung: 800mm x 1550mm
Maximum sash sizes = Fixed light: 3000mm x 3000mm
Outer frames = 55mm, 67mm and 80mm outer frames
Mullions = 68mm or 82mm mullions
Sash = 76mm casement sash
Glazing
Glazing beads
28mm bevelled
28mm sculptured
36mm bevelled
40mm bevelled
44mm bevelled
Glazing method
Dry glazing/Siliconised glazing/Internal glazing/glazing bead
