MATRIX Fully Sculptured Casement
Traditional aesthetics, PVCU performance in casement windows.
Widely chosen for quality look and functionality.
Available in a wide aesthetic palette.
Personalisation Options
Flyscreen
Balustrade
“This casement window sits within the Matrix Fully Sculptured system which was designed to deliver the traditional look and feel of quality timber, whilst providing the performance benefits of PVCU. The VEKA Matrix Fully Sculptured Casement is widely chosen for its aesthetic appeal and unquestionable performance. Available in a wide range of colours and woodgrain options.”
Technical Details
Performance
Energy
Thermal Insulation - Uw = 1.30 W/m2K (Double Glazed)
Thermal Insulation - Uw = 0.96 W/m2K (Triple Glazed)
Comfort
Air tightness = Class 4 (600Pa)
Water tightness = Class 9A (600Pa)
Wind load resistance = Class C4 (1600Pa)
Safety
Burglar resistance = PAS24
Overall Dimensions
Max. dimension & weight
Maximum sash sizes = Top hung = 1400mm x 1400mm
Maximum sash sizes = Side hung = 800mm x 1550mm
Maximum sash sizes = Fixed light = 3000mm x 3000mm
Outer frames = 56mm, 70mm and 85mm outer frames
Mullions = 64mm or 86mm mullions
Sash = 75mm casement sash
Glazing
Glazing beads
28mm sculptured
32mm sculptured
36mm sculptured
40mm bevelled
Glazing method
Dry glazing/Siliconised glazing/Internal glazing/glazing bead
